Top sections standard for gully body Wal-Selecta

Product information

The top sections are available in a standard and in a long version
Standard top sections cover the following types of floor structures
- Type A: Floor structure without any insulation
- Type B: Floor structure is insulated by thickness of floor covering
- Type E: Floor structure with a sealing membrane
- Type F: Floor structure is insulated by two sealing membranes

Infobox

Note: When using the sealing ring (Item No. 5084.90.00) in combination with top sections for ground-level structures A/B/E/F then the maximum height is reduced by 35 mm.

Note: Top sections with slot widths ≤ 8 mm are suitable for barefoot areas.

Note: The top sections should be cut to size between the maximum and minimum adjustable heights depending on the version.

Version	Frame	Grating	Height- adjusta- bility H1min – H1max	Description	Weight	Item number		Downloads	Remember
Version	[mm]	[mm]	[mm]	Description	[kg]	Item number		Downloads	Remember
Plastic Support	Plastic 198 x 198	Slot grating Stainless steel 188 x 188 K 3	45 – 150	Placed loosely	1.5	5084.87.00
Plastic Support	Plastic 198 x 198	Slot grating Stainless steel 188 x 188 K 3	45 – 150	Placed loosely Slip resistant: Class C	1.5	5084.87.11	1
Plastic Support	Plastic 198 x 198	Slot grating Stainless steel 188 x 188 K 3	45 – 150	Bolted	2.0	5084.71.00
Plastic Support	Plastic 198 x 198	Slot grating Stainless steel 188 x 188 K 3	45 – 150	Bolted Slip resistant: Class C	2.0	5084.71.11	1
MEKU Support	Stainless steel 196 x 196	Slot grating Stainless steel 188 x 188 K 3	50 – 155	Bolted	2.3	5084.81.00
MEKU Support	Stainless steel 196 x 196	Slot grating Stainless steel 188 x 188 K 3	50 – 155	Bolted Slip resistant: Class C	2.3	5084.81.11	1
Stainless steel Support	Stainless steel 196 x 196	Slot grating Stainless steel 188 x 188 K 3	45 – 160	Bolted	4.5	5084.89.00
Stainless steel Support	Stainless steel 196 x 196	Slot grating Stainless steel 188 x 188 K 3	45 – 160	Bolted Slip resistant: Class C	4.5	5084.89.11	1
Cast iron Support	Cast iron 200 x 200	Slot grating Cast iron 187 x 187 L 15	60 – 75	Placed loosely Painted	8.7	5084.80.00	1
Cast iron Support	Cast iron 200 x 200	Slot grating Cast iron 187 x 187 L 15	60 – 75	Placed loosely Coated in white epoxy	8.7	5084.83.00	1
Cast iron white epoxy coating Support	Cast iron 197 x 197	Mesh grating Stainless steel 171 x 171 L 15	75 – 95	Placed loosely Non-slip	8.7	5084.84.00	1
Stainless steel leak ring	Stainless steel 200 x 200	Mesh grating Stainless steel 171 x 171 L 15	60 – 185	Placed loosely Non-slip	4.3	5084.92.00	1
Painted cast iron Support	Cast iron 197 x 197	Mesh grating Galvanised steel 171 x 171 M 125	75 – 95	Placed loosely	8.7	5084.85.00	1
Stainless steel Support	Stainless steel 200 x 200	Mesh grating Stainless steel 171 x 171 M 125	60 – 185	Placed loosely Non-slip	4.3	5084.93.00	1
Stainless steel Support	Stainless steel 200 x 200	Ladder grating Stainless steel 171 x 171 M 125	60 – 185	Placed loosely	4.8	5084.94.00	1
Painted cast iron Support	Cast iron 197 x 197	Slot grating Cast iron 171 x 171 M 125	75 – 95	Placed loosely	11.2	5084.82.00	1
Painted cast iron leak ring	Cast iron 197 x 197	Slot grating Cast iron 171 x 171 M 125	75 – 95	Bolted	11.2	5084.86.00	1

Version	Frame	Grating	Height- adjusta- bility H1min – H1max	Description	Weight	Item number

Plastic Support	Plastic 198 x 198 mm	Slot grating Stainless steel 188 x 188 mm K 3	45 – 150 mm	Placed loosely	1.5 kg	5084.87.00
Plastic Support	Plastic 198 x 198 mm	Slot grating Stainless steel 188 x 188 mm K 3	45 – 150 mm	Placed loosely Slip resistant: Class C	1.5 kg	5084.87.11
Plastic Support	Plastic 198 x 198 mm	Slot grating Stainless steel 188 x 188 mm K 3	45 – 150 mm	Bolted	2.0 kg	5084.71.00
Plastic Support	Plastic 198 x 198 mm	Slot grating Stainless steel 188 x 188 mm K 3	45 – 150 mm	Bolted Slip resistant: Class C	2.0 kg	5084.71.11
MEKU Support	Stainless steel 196 x 196 mm	Slot grating Stainless steel 188 x 188 mm K 3	50 – 155 mm	Bolted	2.3 kg	5084.81.00
MEKU Support	Stainless steel 196 x 196 mm	Slot grating Stainless steel 188 x 188 mm K 3	50 – 155 mm	Bolted Slip resistant: Class C	2.3 kg	5084.81.11
Stainless steel Support	Stainless steel 196 x 196 mm	Slot grating Stainless steel 188 x 188 mm K 3	45 – 160 mm	Bolted	4.5 kg	5084.89.00
Stainless steel Support	Stainless steel 196 x 196 mm	Slot grating Stainless steel 188 x 188 mm K 3	45 – 160 mm	Bolted Slip resistant: Class C	4.5 kg	5084.89.11
Cast iron Support	Cast iron 200 x 200 mm	Slot grating Cast iron 187 x 187 mm L 15	60 – 75 mm	Placed loosely Painted	8.7 kg	5084.80.00
Cast iron Support	Cast iron 200 x 200 mm	Slot grating Cast iron 187 x 187 mm L 15	60 – 75 mm	Placed loosely Coated in white epoxy	8.7 kg	5084.83.00
Cast iron white epoxy coating Support	Cast iron 197 x 197 mm	Mesh grating Stainless steel 171 x 171 mm L 15	75 – 95 mm	Placed loosely Non-slip	8.7 kg	5084.84.00
Stainless steel leak ring	Stainless steel 200 x 200 mm	Mesh grating Stainless steel 171 x 171 mm L 15	60 – 185 mm	Placed loosely Non-slip	4.3 kg	5084.92.00
Painted cast iron Support	Cast iron 197 x 197 mm	Mesh grating Galvanised steel 171 x 171 mm M 125	75 – 95 mm	Placed loosely	8.7 kg	5084.85.00
Stainless steel Support	Stainless steel 200 x 200 mm	Mesh grating Stainless steel 171 x 171 mm M 125	60 – 185 mm	Placed loosely Non-slip	4.3 kg	5084.93.00
Stainless steel Support	Stainless steel 200 x 200 mm	Ladder grating Stainless steel 171 x 171 mm M 125	60 – 185 mm	Placed loosely	4.8 kg	5084.94.00
Painted cast iron Support	Cast iron 197 x 197 mm	Slot grating Cast iron 171 x 171 mm M 125	75 – 95 mm	Placed loosely	11.2 kg	5084.82.00
Painted cast iron leak ring	Cast iron 197 x 197 mm	Slot grating Cast iron 171 x 171 mm M 125	75 – 95 mm	Bolted	11.2 kg	5084.86.00
