APLEX roof penetration

Product benefits

  • Versatility and Compatibility: APLEX wall seals accommodate a broad range of perforating piping sizes, from 15 mm to 275 mm.
  • Durability and Resistance: Constructed from corrosion-proof yellow chromated steel and special rubber, the seals offer long-lasting performance.
  • Flexible Design Options: The seals offer design flexibility, allowing for precise location and dimension adjustments either before or after wall construction.
  • Ease of Installation: The seals can be conveniently installed using a plastic tube method during concrete works, simplifying the process.
  • Waterproof and Pressure-Resistant: APLEX provides tailored sealing solutions that are waterproof and specifically designed for areas with pressure water activity.

Product information

  • Massive zinc flange
  • Nuts and washers from stainless steel
  • Screws with strength of 8.8 screwed and welded to the flange
  • Wide sealing, material EPDM with temperature resistance up to 130°C
  • Marking of each product by the hole diameter and the tube diameter range
